Description :
| LED type | SMD 5050 |
| Number LED/m | 60 LED |
| LED pitch | 16.7 mm |
| Step length | 100mm/6 LED |
| Wattage/m | 14.4W±10% |
| Operating voltage | 24VDC |
| Dimensions | 5000x10x2mm |
| Beam angle | 120° |
| IP Rating | IP20 |
| PCB technology | Isolated double layer FPC |
| Ambient temp | Ta= -25°C to 50°C/(max. +70°C) |
| Connection | 3-pin AWG22 wires |
| Control | 0-10V/1-10V/DMX/DALI/PWM |
| Colors | White: 2400K, 2700K, 3000K, 4300K, 5000K, 6000K |
| Part No. | Light color | color temperature | Power/m (W) |
Lumen/m (lm/m) WW |
Lumen/m (lm/m) CW |
CRI |
| DN-F5050XX60S | WW- CW | 2400K-6000K | 13.2 | 420 | 480 | 80 |
