Description :
Product features:
|
LED type
|
SMD 5050
|
|
Number LED/m
|
60 LED
|
|
LED pitch
|
16.7 mm
|
|
Step length
|
100mm/6 LED
|
|
Wattage/m
|
14.4W±10%
|
|
Operating voltage
|
24VDC
|
|
Dimensions
|
5000x12x4.5mm
|
|
Beam angle
|
120°
|
|
IP Rating
|
IP67
|
|
PCB technology
|
Isolated double layer FPC
|
|
Ambient temp
|
Ta= -25°C to 50°C/(max. +70°C)
|
|
Connection
|
2-pin AWG22 wires or male/female connectors
|
|
Control
|
0-10V/1-10V/DMX/DALI/PWM
|
|
Colors
|
White/red/green/blue/yellow/pink/purple/amber
|
Parameters:
|
Part No.
|
Light color
|
color temperature
|
Power/m
(W) |
Lumen/m
(lm/m) |
Efficacy
(lm/W) |
CRI
|
|
DN-F5050WW60-L24
|
WW
|
2400K
|
14.4
|
780
|
60
|
80
|
|
DN-F5050WW60-L27
|
WW
|
2700K
|
14.4
|
840
|
65
|
80
|
|
DN-F5050WW60-L30
|
WW
|
3000K
|
14.4
|
870
|
67
|
80
|
|
DN-F5050NW60-L43
|
NW
|
4300K
|
14.4
|
900
|
69
|
80
|
|
DN-F5050DW60-L50
|
DW
|
5000K
|
14.4
|
930
|
72
|
80
|
|
DN-F5050CW60-L60
|
CW
|
6000K
|
14.4
|
960
|
74
|
80
|
